Hot working tool steels are used in the hot-forming of work-pieces made of iron and non-ferrous metals as well as alloy derivatives at high temperatures. They are utilised in processes such as pressure die casting, continuous casting, extrusion and drop forging as well as in tube and glass manufacturing.
Item No :
CHINA SUPPLIER Hot Work Tool SteelOrder(MOQ) :
500KGSProduct Origin :
ChinaSurface :
Black Surface or Machined SurfaceShipping Port :
Main Port of ChinaLead Time :
7-60 DaysWeight :
Depend on the details quantitySize :
Dia20---500mm,Thickness: 20-500mmGrade :
H13/1.2344, H11/1.2343 1.2365,1.2367 etc1. Composition: Hot work tool steel round bars are typically made from steel alloys that contain high levels of chromium, tungsten, and molybdenum. These alloys provide excellent resistance to heat, wear, and deformation.
2. Grade: Hot work tool steel round bars are available in different grades, each with its own unique properties and characteristics. Examples of common grades include H11, H13, and H21.
3. Surface Treatment: Hot work tool steel round bars can be surface treated to improve their performance in specific applications. For example, they can be coated with a material like diamond-like carbon (DLC) to improve wear resistance.
4. Applications: Hot work tool steel round bars are commonly used in a variety of industries, including automotive, aerospace, energy, and manufacturing. They are often used to manufacture dies and molds for applications such as forging, extrusion, and casting.
5. Processing: Hot work tool steel round bars can be processed using a variety of techniques, including machining, forging, and heat treatment. The specific processing method used will depend on the desired properties and application of the final product.
Product Specification
|
Grade |
Round bar |
Flat bar |
Plate |
Block |
|||
|
AISI/SAE |
DIN |
W.Nr |
JIS |
||||
|
H11 |
X38CrMoV51 |
1.2343 |
SKD6 |
√ |
√ |
√ |
|
|
H13 |
X40CrMoV51 |
1.2344 |
SKD61 |
√ |
√ |
√ |
|
|
H21 |
X30WCrV9-3 |
1.2581 |
SKD5 |
√ |
√ |
√ |
|
|
L6 |
55NiCrMoV6 |
1.2713 |
SKT4 |
√ |
√ |
√ |
|
|
56NiCrMoV7 |
1.2714 |
√ |
√ |
√ |
|||
|
X45NiCrMo4 |
1.2767 |
√ |
√ |
√ |
|||
Round bar:Dia10-610mm
Flat bar & Plate : Thickness16-350mm X Width 100-610mm
Remarks: we can accept some special size that beyond our available size.
Product image
Pre-hardened plastic mould steels are widely used for manufacturing mould for plastic because of their four main properties and characteristics:Wear Resistance Corrosion, Resistance Mirror, Finish ability,Surface Work ability. These steels are quenched and tempered before being manufactured into mould for plastic, therefore the deformation and cracking of mould resulted from heat treatment can be avoided.
read More
Hot working tool steels are used in the hot-forming of work-pieces made of iron and non-ferrous metals as well as alloy derivatives at high temperatures. They are utilised in processes such as pressure die casting, continuous casting, extrusion and drop forging as well as in tube and glass manufacturing.
read More
Cold working tool steels are high carbon steels that contain alloy additions of tungsten, manganese, chromium and molybdenum, which increase the hardenability of the steels. The high carbon content produces adequate wear resistance for short run applications. Cold work tool steels are used for cutting and pressing tools, for dies and knives, for stamping and drawing tools, hobs, thread rolling tools and in many other applications due to their typical properties – high hardness, good toughness and compressive strength and high wear resistance.
read More
Bearing steels are used for ball and roller bearing applications and are comprised of low carbon (0.10 to 0.20% C) case-hardened steels and high carbon (-1.0% C) through-hardened steels.
read More
Spring steel is used for highly stressed, quenched and tempered springs, hand tools, larger diameter coiled springsand rock drilling studs in vehicle and tractor industries
read More
